The Single Stainless Steel Sink Top Mount comes with stainless steel fixing clips, a full-circle silicone seal, a basket drain assembly, and a paper cutout template. It's ready for installation right out of the box. Its clean, sleek appearance makes it suitable for quartz, granite, and wood countertops.
The Single Stainless Steel Sink Top Mount is made of 304 stainless steel with a Cr ≈ 18 and a Ni ≈ 8 rating, offering corrosion resistance superior to 201 stainless steel. The standard plate thickness is 18 gauge ≈ 1.2 mm, with a reinforced version available in 16 gauge ≈ 1.5 mm. The surface has a longitudinal brushed hardness of approximately 3H, making it less susceptible to marks from daily tableware wear. It also offers a salt spray resistance of ≥ 72 hours, maintaining its metallic luster even under the long-term effects of cooking fumes and cleaning agents. The trough is a one-piece, extruded structure with no welds, and boasts a single-point load capacity of ≥ 40 kg, making it suitable for cleaning heavy cast iron pots.
Recommended dimensions are 680 × 480 mm, corresponding to an opening of approximately 620 × 440 mm; the effective inner tank is approximately 610 × 420 × 220 mm, with an equivalent volume of approximately 56–60 L. The inner wall features a gentle 1.5–2° slope, with radial flow from the bottom to the drain outlet. The flange on the countertop forms a water barrier, preventing splashback from dripping onto the countertop. The single basin layout frees up space, allowing baking trays and woks to sit flat for soaking.
The Single Stainless Steel Sink Top Mount features a 3 mm composite sound-absorbing pad with a coverage of ≥70% on the outer wall, significantly dampening the sound of falling water and metal collisions. The bottom is sprayed with an anti-condensation coating of ≥0.4 mm to reduce condensation during cold summer conditions and protect the wooden cabinet. An EVA cushioning strip is installed at the contact point with the countertop, ensuring nighttime operation without disturbing neighboring rooms.
The interior features fine straight-grain brushing and R10 rounded corners, ensuring smooth cloth movement. The drain assembly is an internationally compatible 114 mm, suitable for direct connection to a garbage disposal or basket drain. The water seal is ≥50 mm, providing enhanced odor control. After 500 daily wipes with a neutral detergent, the color difference (ΔE) remains below 1.0, and the surface resists yellowing or darkening.
The Single Stainless Steel Sink Top Mount eliminates the need to dismantle or modify the undercounter support. Equipped with eight elastic clips and a full-circle silicone seal, it accommodates countertop thicknesses of 20–40 mm. Drilling, test installation, gluing, and reverse fastening can be completed in under 30 minutes. A paper template and ruler are included, allowing carpenters to cut along the lines, ensuring high tolerance for installation errors and minimal on-site rework.
The Single Stainless Steel Sink Top Mount fits common 30" base cabinets with a clear undercounter width of 680mm or greater. One to three faucet holes are reserved, with a center spacing of 35mm. This allows for on-site expansion of soap dispensers or water purifiers. The drain assembly features a 40/50mm adapter for direct connection to mainstream P-trap or floor drain systems, ensuring smoother integration into renovation projects.
Partial renovation of an old kitchen without removing cabinets. Holes and countertop grooves are cut using a template in quartz or wood-based panels. The 27-inch single basin provides ample depth for high-sided pots and baking trays. The brushed finish is fingerprint-resistant and easy to clean. Installation is completed within one business day, allowing residents to resume use that same evening without major plumbing or electrical modifications.
Lease renewals require rapid restoration. Anti-condensation coating reduces the risk of moisture in the cabinets. Sound-absorbing pads ensure quiet operation at night. 114-grade piping is used. The standard 114mm outlet is directly connected to the existing pipeline. The cleaning team can remove coffee stains and oil stains with a neutral detergent. Inspections only require checking the clips and seals, improving turnover efficiency.
Cupware is centrally cleaned during workdays. A 220mm deep cavity with a flanged water barrier prevents splashing on the dry countertop. The countertop structure facilitates later maintenance. During cleaning, the drain or faucet can be replaced from the top, minimizing downtime. The garbage disposal is directly connected to the 114mm outlet for more reliable daily odor control.
The space behind the bar is compact. The 680×480mm shape provides ample volume without occupying aisles. Milk jugs and pour-overs can be fully immersed and washed. The brushed surface and R10 rounded corners reduce grease adhesion. Final cleaning can be completed within 10 minutes after closing, making it easier to prepare for the next day's opening.
